HIKVISION DS-KH6310-W User Manual

Video Intercom Indoor Station·User Manual
95
Switch
Video Compression
Standard
H.264
Resolution
640 × 480
Video Frame Rate
PAL: 25 fps, NTSC: 30 fps
Display Parameters
Display Screen
10-Inch Colorful TFT LCD
Resolution
1024 × 600
Operation Method
Capacitive Touch Screen, Touch Key
Operation Interface
Flattened UI Operation Interface
Audio Parameters
Audio Input
Build-in Omnidirectional Microphone
Audio Output
Build-in Loudspeaker
Audio Compression
Standard
G.711 U
Audio Compression
Rate
64 Kbps
Audio Quality
Noise Suppression and Echo Cancellation
Network Parameters
Ethernet
10/100 Mbps Self-Adaptive Ethernet
Network Protocol
TCP/IP, SNMP, SIP, RTSP
Alarm Parameters
Alarm Input
8-ch Alarm Input Sensor
Device Interfaces
Internet Access
1 RJ45 10/100 Mbps Self-Adaptive Internet
Interface
RS-485
2 RS-485 Half-Duplex Port
I/O Output
2
TF Card (Micro SD Card)
TF Card; Supporting Max. 32GB
Other Parameters
Power Supply
DC 24V, Power Over Network Cable (DS-KAD606,
DS-KAD612)
DC 12V
Power Consumption
≤10 W

HIKVISION DS-KH6310-W Specifications

General

Color	Yes
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Number of buttons	4 buttons
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Display resolution	800 x 480 pixels
Display technology	LCD/TFT
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Proper use	Indoor
Control type	Buttons, Touch
Product color	White
Operating system installed	Linux
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
