HIKVISION DS-KH6310-W User Manual

Video Intercom Indoor Station·User Manual
18
6. After installing the installation plate, install the indoor station onto the installation
plate according to the direction of the arrow, as shown in the figure below.
Figure 5-4 Install the Indoor Station
7. Pull the device downwards to hook the indoor station with the installation plate after
inserting the indoor station into the gang box.
8. Secure the door station by locking the lock catch on the rear panel of indoor station
onto the lock hole of the installation plate, as shown in the figure below.
Lock Hole
Lock Catch
Figure 5-5 Secure the Indoor Station

HIKVISION DS-KH6310-W Specifications

General

Color	Yes
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Number of buttons	4 buttons
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Display resolution	800 x 480 pixels
Display technology	LCD/TFT
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Proper use	Indoor
Control type	Buttons, Touch
Product color	White
Operating system installed	Linux
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
