Video Intercom Indoor Station·Quick Start Guide
6
Zone Detector Input Terminal 4
Zone Detector Input Terminal 3
Zone Detector Input Terminal 2
Zone Detector Input Terminal 1
2.2 Terminals and Interfaces of DS-KH6310-W/
DS-KH6310
Figure 2-2 terminals of DS-KH6310-W/DS-KH6310
Table 2-2 Descriptions of Terminals and Interfaces
RS-485 Communication Interfaces
Zone Detector Input Terminal 1
Zone Detector Input Terminal 2
Zone Detector Input Terminal 3
Zone Detector Input Terminal 4
Zone Detector Input Terminal 5
Zone Detector Input Terminal 6
Zone Detector Input Terminal 7
Zone Detector Input Terminal 8
To Next Page
