HIKVISION DS-KV6113 Series User Manual

2) Set the Negave Floor.
3) Select the Interface Type as RS-485 or Network Interface. And enable the
elevator control.
-
If you select RS-485, make sure you have connected the door
staon to the
elevator controller with RS-485 wire.
-
If you select Network interface, enter the elevator controller's IP address,
port No., user name, and password.
Note
•
Up to 4 elevator controllers can be connected to one door staon.
•
Up to 10 negave oors can be added.
•
Make sure the interface types of elevator controllers, which are connected
to the same door staon, are consistent.
Input and Output
Click Intercom → Input and Output to enter the sengs page.
Figure 5-15 IO Input and Output
Select I/O Input No., Input, I/O Output No. and Output.
Click Save to enable the sengs.
Time Parameters
Click Time Parameters to enter the page.
Congure the me parameters and click Save.
Video Intercom Villa Door
Staon User Manual
33

HIKVISION DS-KV6113 Series Specifications

General

Audio Bit Rate	64 Kbps
Ingress Protection	IP65
Operation System	Embedded Linux
Camera	2 MP
Resolution	1920 × 1080
Frame Rate	25/30 fps
Video Compression	H.264
Audio Input	Built-in microphone
Audio Output	Built-in speaker
Network Protocol	TCP/IP, RTSP
Interface	1 RJ45 10/100 Mbps Self-Adaptive Ethernet Interface
Relay Output	1
RS-485	1
Power Supply	DC 12V
Operating Humidity	10% to 90%
Power Consumption	≤12 W
