HIKVISION DS-KV6113 Series User Manual

higher frame rate is advantageous when there is movement in the video
stream, as it maintains image quality throughout.
Max. Bitrate
Set the max. bitrate from 32 to 16384 Kbps. The higher value corresponds to
the higher video quality, but the beer bandwidth is required.
Video Encoding
The device supports H.264.
I Frame Interval
Set I Frame Interval from 1 to 400.
Audio Encoding
The device support G.711ulaw.
4.
Click Save to enable the
sengs.
Audio Parameters
Steps
1.
Click Video/Audio → Audio to enter the sengs page.
2.
Adjust the Input Volume, Output Volume and Speak Volume.
Note
Available range of volume: 0 to 10.
3.
Click Save to enable the sengs.
5.3.5 Image
Sengs
Display Sengs
Congure the image adjustment, backlight sengs and other parameters in display
sengs.
Steps
1.
Click Image → Display
Sengs to enter the display sengs page.
Video Intercom Villa Door
Staon User Manual
26

HIKVISION DS-KV6113 Series Specifications

General

Audio Bit Rate	64 Kbps
Ingress Protection	IP65
Operation System	Embedded Linux
Camera	2 MP
Resolution	1920 × 1080
Frame Rate	25/30 fps
Video Compression	H.264
Audio Input	Built-in microphone
Audio Output	Built-in speaker
Network Protocol	TCP/IP, RTSP
Interface	1 RJ45 10/100 Mbps Self-Adaptive Ethernet Interface
Relay Output	1
RS-485	1
Power Supply	DC 12V
Operating Humidity	10% to 90%
Power Consumption	≤12 W
