HIKVISION DS-KV8102-IP User Manual

Video Intercom Door Station·User Manual
27
 Click Restore Default Settings button, all default settings, excluding network
parameters, will be restored.
 Click Restore All button, all default settings, including network parameters, will be
restored. The device will be reset to inactivated status.
User
Purpose:
You can edit the password for logging in the device.
Steps:
1. Click the User button to enter the user information editing interface.
Figure 7-19 Select User Name
2. Select the user to edit and click the Modify button to enter the user parameter
interface.
Figure 7-20 Modify User Information
3. Enter the new password, and confirm it.
4. Click the Save button to realize the editing of password.
 The new password and confirm password should be identical.

HIKVISION DS-KV8102-IP Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Number of buttons	1 buttons
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Megapixel	1.3 MP
Sensor type	CMOS
Maximum frame rate	25 fps
Maximum video resolution	1280 x 720 pixels
Proper use	Outdoor
Product color	Gray
Outdoor unit housing material	Plastic
International Protection (IP) code	IP65
LED type	IR
Outdoor unit power type	AC/DC
Power consumption (typical)	12 W
Operating relative humidity (H-H)	10 - 90 %
Door station operating temperature (T-T)	-40 - 70 °C
Operating system installed	Linux
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP
Indoor unit included	No

Weight and Dimensions

Depth	54.4 mm
Width	97 mm
Height	164 mm
Door station dimensions (WxDxH)	97 x 54.4 x 164 mm
