Rail Network Video Recorder Quick Start Guide
11
4. Use a screwdriver to loosen and remove the two set screws marked in the figure.
Figure 3. 4 Loosen and Remove Screws
5. Separate the HDD box in to parts.
Figure 3. 5 HDD Box Parts
6. Place the first HDD into the HDD box and tightly insert the first HDD into the bottom, with the PCB facing
downward.
Figure 3. 6 Install the First HDD
7. Place the second HDD into the HDD box, with the PCB facing upward. After the HDD is totally placed into
the bracket, tightly insert the second HDD into the socket.
To Next Page
