Rail Network Video Recorder Quick Start Guide
12
Figure 3. 7 Install the Second HDD
8. Tighten the two screws marked in the figure to fix the HDD. Do the same things to fix the other HDD at the
back side.
Figure 3. 8 Fix HDDs
9. Tighten the 4 set screws on the side of the HDD box, shown as the following figure.
Figure 3. 9 Fix HDDs
10. Align the protective cover of the HDD box with the line marked in the figure, and assemble the whole HDD
box.
