iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual
UM iDS-2CD7xxG0-xxxxx 021021NA 47
3. See Set Arming Schedule for setting scheduled time. See Linkage Method Settings for setting linkage
method.
4. Click Save.
Set Intrusion Detection
Detects objects entering and loitering in a pre-defined virtual region, after which the device can take
linkage actions.
Steps
1. Go to Configuration → Event → Smart Event → Intrusion Detection.
2. Check Enable.
3. Select a Region. For the detection region settings, refer to Draw Area.
4. Set rules.
• Sensitivity: Percentage of the body part of an acceptable target that enters the pre-defined region.
Sensitivity = 100 - S1/ST × 100. S1 is the target body part that crosses the pre-defined region. ST is
the complete target body. The higher the sensitivity value, the more easily the alarm is triggered.
• Threshold: The threshold for the time the object loiters in the region. If the time the object stays
exceeds the threshold, the alarm is triggered. The larger the value, the longer the alarm trigger time.
• Object: You can specify the object type to be detected.
Figure 6-4 Set Rule
5. Optional: You can set the parameters of multiple areas by repeating the above steps.
6. For arming schedule settings, see Set Arming Schedule. For linkage method settings, see Linkage
Method Settings.
7. Click Save.
