Table 3-2 Fisheye View Icon Description
Icon
Description
Icon
Description
180° Panorama ( )
Switch the Live View
image to the 180°
panorama view.
360° Panorama ( )
Switch the Live View
image to the 360°
panorama view.
PTZ Expansion ( )
The PTZ Expansion is
the close-up view of
some defined area in
the fisheye view or
panorama expansion.
It supports the
electronic PTZ
function, also called
e-PTZ.
Radial Expansion ( )
In radial expansion
mode, the whole
wide-angle view of
the fisheye camera is
displayed. This view
mode is called
Fisheye View because
it approximates the
vision of a fish’s
convex eye. The lens
produces curvilinear
images of a large
area, while distorting
the perspective and
angles of objects in
the image.
3.9 3D Positioning
3D Positioning zooms in/out a specific live image area.
Steps
1. Start live view, and click .
2. Zoom in/out the image.
– Zoom in: Click on the desired position in the video image and drag a rectangle area in the
lower right direction to zoom in.
– Zoom out: Drag a rectangle area in the upper left direction to move the position to the center
and enable the rectangle area to zoom out.
