Network Video Recorder User Manual
72
way street.
Steps
1. Go to Smart Analysis → Smart Event Settings → Other Events.
2. Select a camera.
3. Click Parking.
Figure 6-6 Parking Detection
4. Check Enable Parking Detection.
5. Optional: Check Save VCA Picture to save the captured parking detection pictures.
6. Set parking detection parameters.
1) Select Arming Area.
Note
Up to 4 areas are selectable.
2) Set Time Threshold.
Time Threshold
The time of a vehicle staying in the region. If the value is 10, an alarm will be triggered after
the vehicle has stayed in the region for 10 s. Range: [5-20].
3) Set Sensitivity.
Sensitivity
Similarity of the background image to the object. The higher the value is, more easily the
detection alarm will be triggered.
