KB88113 Vandal-Resistant Video Intercom Doorbell User Manual
UM KB8113 Doorbell 021821NA 30
Set the master station IP address and master station SIP client Port.
Set the private SIP server IP address and private SIP Server Port.
Set the SIP Client Port.
Enter the password.
Click Save to enable the settings.
Time Parameters
Click Intercom → Time Parameters to enter the page.
Configure the time parameters and click Save.
Maximum speaking time varies from 90s to 120s, and maximum message time
varies from 30s to 60s.
Intercom Protocol
Slide to enable protocol 1.0.
Ring-Back Tone Settings
Click Intercom → Ringbacktone Settings to enter the settings page.
Click Add to select the ring tone from PC.
Available Audio Format: WAV,AAC
Size: Less than 600 KB
Sample Rate: 8000 Hz, mono
Press Button to Call
Click Intercom → Press Button to Call to enter the settings page.
Set the parameters.
• Edit call no. for every button.
• Check Call Management Center to set the button calling center.
If you check Call Management Center and set the call no. as well, call
management center has higher privilege than call no.
I/O Settings
Click Intercom → I/O Settings to enter the I/O input and output settings page.
