Actual functions are subject to UVSS models.
Close control cabinet door in time to avoid short circuit or other dangers caused by rain.
1.5 Working Process
The UVSS supports bi-directional detection. The location of the product and vehicle driving
direction are shown below.
Figure 1-5 Driving Direction
When a vehicle stops above the UVSS, the photoelectric module 1 will be triggered and the speed
detection module will stand by, waiting to send capture command to the camera after detecting
vehicle move. It can also send back vehicle speed in real time to adjust line frequency of the
camera, so as to reduce image distortion.
During capturing, the LED supplement light will keep on to brighten up vehicle undercarriage.
