EURO 46 V10 Programming Manual
11. Press b or d to select another device address
to program (1-7) or press the key to return to the
Engineer Menu.
Programming Readers for Entry Control or Access Control: Assign Keypads/Readers
1. Press b or to scroll to ‘ASSIGN KEYPADS/
READERS’. Press .
2. Press b or d to select the address. Press .
3. ‘Type’ will be displayed. Press 1 to select the
reader. Press
4. ‘Reader is’ will be displayed. Press for ‘Access
Control’ or press for ‘Entry Control’ (as shown in
example) & Press .
5. ‘Set Point Sets’ will be displayed. Select the area(s).
Press .
6. ‘Set Point Unsets’ will be displayed. Select the area(s).
Press .
7. ‘Set Point In’ will be displayed. Enter the Area in which
the keypad is situated and press .
8. ‘Lock Open Time’ will be displayed. Enter the Lock Open
Time in seconds and press . (Max 255 seconds).
9. ‘Door Open Time’ will be displayed. Enter the Door Open
Time in seconds and press . (Max 255 seconds).
10. ‘Door Contact No.’ will be displayed. Press to enter
a number and then press again.
11. ‘Access Control Description’ will be displayed. Press
.
ASSIGN KEYPADS/
READERS?
Address
[1]
Type
Keypad [0]
Reader is
Set Point [0]
Set Point Sets
[01ABCD]
Lock Open Time
Seconds [005]
Door Open Time
Seconds [010]
Set Point Unsets
[01ABCD]
Set Point In
[01ABCD]
Set Point In
[01ABCD]
Set Point
Description?
