Hill-Rom Liko Multirall 200 User Manual

18
7EN125103 Rev. 13 • 2020
www.hillrom.com
Room-to-Room transfer
Connect the Strap Gripper with both hooks to the
Room-to-Room Strap, see illustraon to the right.
R2R strap
Install the li according to assembly
alternave A. Install the Strap Gripper
in accordance with applicable assembly
instrucons.
Room 1
Room 2
The Liko
TM
R2R (Room-to-Room) system is an eecve soluon for safe and easy transfer of paents between two or more
rooms. The R2R system is mounted without making openings in walls over doors, and full isolaon is therefore retained
between the rooms supported by the system.
In order to perform room-to-room transfers with Mulrall™ 200 overhead li, the following condions are required:
• Both rooms have separate rail systems, each with a carriage mounted in the rail.
• Between the rooms, suspended under the doorframe, a Room-to-Room Strap is mounted, acng as a bridge between the
rooms.
• Mulrall™ 200 overhead li is equipped with a Strap Gripper, which is installed to either of the Extension Belt connectors
on the li.
• An adjustable extension belt is mounted to the carriage, in order to obtain an appropriate liing height. Alternavely, if the
liing height becomes too low when using the Extension Belt, the Extension Arm Mulrall/Mulrall Helping Hand can be
used for connecng Q-Link II or Q-Link directly to the carriage hook, providing a maximum liing height.
Room-to-Room Transfer
Below is a descripon of an R2R transfer with Mulrall, Strap Gripper, Room-to-Room Strap and adjustable Extension belt.
Check carefully at each stage that the Q-Link or Q-Link II is correctly applied to the carriage hook/extension belt!
Install the Room-to-Room
Strap between the two rooms.
For installaon and length
adjustment, see applicable
assembly instrucons.
Mulrall is pending in the carriage, alternavely
in an extension belt, in room 1. Move the li
with the paent forwards, as close as possible
to the doorway. Lower the paent as far down
as is comfortably possible, but not so far that
the caregiver cannot reach the Room-to-Room
Strap with the Strap Gripper.
Extension Belt
Strap Gripper

Hill-Rom Liko Multirall 200 Specifications

General

Category	Ceiling Lift
Maximum Load Capacity	200 kg
Power Source	Electric
Emergency Stop	Yes
Power Supply	24 V DC
Lifting Speed	0.05 m/s
Material	Aluminum
Emergency Lowering	Yes, electrical and manual
