5th Wheel (P7900B1 and Newer)
Chapter 5: Parts List
5 - 46 Centrella® Smart+ Bed Service Manual (193588 REV 12)
5TH WHEEL (P7900B1 AND NEWER)
Item Part Number Description Quantity
1 191052S 5TH WHEEL 1
2 129623 RIVET,BARB,.25,1.05,DOME,NYL 2
3 190237 NUT, HEX,FLG,NYLOC, M6-1,9.1, ZN 4
4
70341
a
a. If service is being done on the 5th wheel cable assembly, when you install the cable latch plate (attached with
the screw, item 4), install the cable latch plate on the foot-end side of the cable end support (item 9) (see “5th
Wheel Assembly Components—Replacement” on page 4-108). After the parts are installed, make sure the 5th
wheel function operates correctly.
SCREW,RLG,PAN,TX,M5,.472,STL 1
5 71993 SCREW,ROLL,PAN,TX,M5X.8,.630 1
6 167173 PIVOT SYSTEM 2
7 19124 WIRE TIE 2
8 197538 SUPPORT, CABLE END 1
9 198613 CABLE, 5TH WHEEL 1
