Part 2 - Getting Started
28
1 Login/Logout
Log into and out from accounts. If in the logged in
state, the account ID is shown. If in the logged out
state, the login icon is shown.
2 Layout
Used to change the screen layout to single screen,
2x2 or 3x3.
3 Previous/Next Group
Loads the previous/next screen group.
4 Display
• OSD (On Screen Display): Enables/disables the
OSD feature.
• Full: Displays the video in full screen mode.
• Aspect Ratio: Select whether to enable the
original aspect ratio of video transmitted from the
camera.
5 Freeze
Freezes the screen. Select Freeze again to unfreeze.
6 Alarm
Pressing this button while the alarm has been
activated resets all NVR outputs, including the built-
in buzzer.
7 Panic Recording
Activates/deactivates Panic Recording.
8 Sequence
Initiates Sequence in the same manner as pressing
the SEQUENCE button while in Live mode. To exit,
select Sequence once more or press the SEQUENCE
button on the remote control. The
icon is
displayed on the upper right part of the screen while
Sequence is in progress.
Live Mode
Live Menu
Press the MENU button on the remote control while in Live mode to bring up the Live menu on the top of the screen.
Press MENU button once more to hide the menu. Use the Arrow buttons on the remote control to select the menu
options.
1
2
3 4 5 6 7 8 9 0 ! @
#
1
Login/Logout
2
Layout
3
Previous Group,
Next Group
4
Display
5
Freeze
6
Alarm
7
Panic Recording
8
Sequence
9
Select Camera
0
Search Mode
!
Setup
@
Wizard
#
Status Indication
Placing the mouse pointer near the top portion of the screen also displays the Live menu.
