Connectors
Video In Ethernet: 4/9 ports (SmartIP-4EDX/SmartIP-8EDX)
Camera Power Out Ethernet: 4/8 ports (SmartIP-4EDX/SmartIP-8EDX)
Monitor Out
HDMI: 1 HDMI
VGA: 1 DB15
Audio Out 1 RCA connector
Alarm Terminal block
Ethernet Port 1 RJ-45
eSATA Port 1 eSATA
RS-232 Serial Port Terminal block, text insertion (POS/ATM)
IR Remote Control Port Remote Control
USB Ports
1 x USB 2.0, 1 x USB 3.0
(5V, less than 0.5A)
Storage
Internal Storage 2 SATA2 bays
External Storage
eSATA 1 port
Clip Copy Device USB Storage Device (USB HDD, USB Memory, etc.)
Some hard disks may not function properly when mounted on to this product. Refer to the compatibility chart below before
mounting any additional hard disk on to the product. Hard disk compatibility chart is subject to change without notice.
Contact your retailer for the latest compatibility chart.
Storage Manufacturer Model Note
1TB
TOSHIBA DT01ACA100
Western Digital WD10PURX-64D85Y0
2TB
Western Digital WD20PURX-64P6ZY0
TOSHIBA DT01ACA200
3TB
Western Digital WD30PURX-64P6ZY0
TOSHIBA DT01ACA300
4TB Western Digital WD40PURX-64GVNY0
