Maintenance
Vacuum Motor Replacement
Only qualified maintenance personnel are to
perform the following repairs.
Seul le personnel d'entretien qualifié peut effectuer
des réparations
1. Turn off all switches and unplug machine.
2. Remove recovery tank.
3. Remove the (2) screws that fasten the solution
tank to the frame, and tilt tank back to expose the
inside of the frame.
4. Locate the vacuum motor wires and disconnect at
the connector. Close the solution tank.
5. Remove the (6) screws holding the vacuum motor
cover to the solution tank.
6. Remove the vacuum motor.
7. Reverse process to install vacuum motor.
HIL56084 - Operators Manual - Trident EX7
