8 English
3.3.2 Li-ion battery charge state display
Status Meaning
3 LEDs light, 1 LED blinks. • Charge state: 75 % to 100 %
2 LEDs light, 1 LED blinks. • Charge state: 50 % to 75 %
1 LED lights, 1 LED blinks. • Charge state: 25 % to 50 %
1 LED blinks. • Charge state: < 25 %
3.4 Items supplied
Charger, operating instructions.
4 Technical data
C 4/36-MC4
Output voltage
7.2 V …36 V
Weight
3.7 lb
(1.7 kg)
Output
power
100...127 V
90 W
5 Operation
5.1 Switching the charger on
▶ Plug the supply cord into the power outlet.
◁ The green supply voltage LED on the charger lights.
Printed: 20.07.2017 | Doc-Nr: PUB / 5253187 / 000 / 05
