  • V
    vjonesAug 16, 2025
    What to do if Hilti DST 20-CA Saw blade is jammed in the kerf and the saw doesn’t start?
    • J
      Jeremy MilesAug 16, 2025
      If your Hilti Saw blade is jammed in the kerf and the saw won’t start, it could be due to these reasons: * A piece of steel cut free is jammed in the kerf: Carefully try to free the saw blade by moving the saw head forward and back alternately. Once the blade moves freely, attempt to start the blade drive. Use caution to avoid excessive force that could cause damage. If the saw blade remains stuck, disconnect it from the saw and use a breaker/jackhammer to carefully chisel away concrete until the blade is free. * The part cut free is pressing against the saw blade: Disconnect the saw blade from the saw. Remove the part that has been cut free.
  • E
    Ernest WillisAug 18, 2025
    What to do if the saw blade slips on a Hilti Saw?
    • J
      Julie MorrisAug 18, 2025
      If the saw blade slips on your Hilti Saw, consider these potential causes and solutions: * Insufficient tightening torque: Grease the thread of the clamping screw and tighten it to the specified torque. * Contaminated clamping surfaces: Clean and degrease the clamping surfaces of the flange and saw blade. * Damaged threads: Clean and inspect the threads of the clamping screw and inner flange. Replace if necessary. * Stiff clamping screw thread: Grease the thread of the clamping screw.
  • W
    William CortezAug 21, 2025
    Why does my Hilti DST 20-CA have low sawing performance?
    • C
      Caroline SanchezAug 22, 2025
      Low sawing performance with your Hilti Saw can stem from a few reasons. First, ensure the saw blade specification is correct for the material you're cutting; if it's unsuitable, change to the right specification. Second, check the depth of cut; an excessive depth can hinder performance, so reduce it. Finally, the saw advance speed might be too low; try increasing it to improve performance.
  • E
    elewisAug 28, 2025
    How to fix a Hilti DST 20-CA when the cut is not straight?
    • D
      Douglas LynchAug 28, 2025
      If your Hilti Saw isn't cutting straight, several factors could be the cause: * Inadequate blade tension or a blunt saw blade: Change the saw blade, paying attention to the specification. * Improper guide cut: Ensure you're adhering to the recommended guide values. * Flange issues: Check the flange is seated correctly and the securing screw's tightening torque is correct. Repeat the flange installation procedure if needed. * Guide roller play: Inspect the rollers and adjust them. If adjustment isn't enough, replace the rollers or guide rail. * Loose rail fastenings: Check and refasten the rails. * Rail distortion: Install additional rail supports.
  • B
    Beverly RussellAug 31, 2025
    Why is the Hilti DST 20-CA performance so low?
    • E
      Edward ThomasAug 31, 2025
      Low sawing performance on your Hilti Saw can stem from several reasons: * Incorrect blade: Ensure the saw blade specification is correct for the material you're cutting. Change to the right specification if needed. * Excessive cutting depth: Reduce the depth of cut. * Slow advance speed: Increase the saw advance speed. * Blade wandering: Refer to the troubleshooting steps for a cut that isn't straight. * High reinforcement content: If possible, reposition the cut to avoid areas with high reinforcement. * Incorrect blade speed: Set the speed of rotation correctly.
  • M
    mcrawfordSep 3, 2025
    Why is my Hilti DST 20-CA's sawing performance low?
    • D
      Danielle PowellSep 3, 2025
      There are several reasons for low sawing performance: * The saw blade specification might be unsuitable, so check and change to the correct one. * The depth of cut may be excessive, so reduce it. * The saw advance speed might be too low, so increase it. * A drop in performance can be caused by the blade wandering off course. See the troubleshooting section regarding cuts that are not straight. * A drop in performance may be caused by high reinforcement content. If so, make the cut in a different position. * The saw blade speed of rotation might be too high or too low, so set the speed of rotation correctly.
  • C
    christopher58Sep 5, 2025
    How to fix a Hilti Saw cut that is not straight?
    • C
      Christine TaylorSep 5, 2025
      A cut that is not straight can be caused by several factors: * Inadequate blade tension. Change the saw blade. * A blunt saw blade. Change the saw blade, paying attention to the specification. * An inaccurate guide cut, or failure to make one at all. Check whether the given guide values were adhered to. * Excessive play at the guide rollers. Check the play at the rollers and adjust them correctly. If adjustment isn't enough, replace the rollers or the guide rail. * Loose rail fastenings. Check the fastenings and refasten the rails. * Rail distortion (twisting). Install additional rail supports.
  • V
    Vernon ReynoldsSep 9, 2025
    What to do if the Hilti DST 20-CA Saw blade is jammed in the kerf and the saw doesn’t start?
    • A
      Andrea HernandezSep 9, 2025
      If the saw blade is jammed, it could be due to: * A piece of steel cut free jammed in the kerf. Try to lift the saw blade out of the kerf by alternately moving the saw head forward and back (advance / return). Try to start the blade drive as soon as the blade can be moved freely. Avoid using excessive force, as this could cause damage. If the saw blade can’t be moved: Disconnect the saw blade from the saw and use a breaker / jackhammer to chisel away concrete until the blade is free. * The part cut free pressing against the saw blade. Disconnect the saw blade from the saw. Remove the part that has been cut free.
  • J
    jacob21Sep 12, 2025
    Why is there stiff movement of the fastening bolts on the Hilti DST 20-CA Saw arm?
    • T
      Tasha GriffinSep 12, 2025
      Stiff movement of the fastening bolts on the saw arm can occur if the thread or the contact surfaces of the flange are dirty. Clean thoroughly, removing any dirt adhering to parts.
  • T
    Troy BarnesNov 23, 2025
    How to fix a cut that is not straight with Hilti DST 20-CA?
    • H
      Heather ThompsonNov 24, 2025
      A cut that is not straight when using the Hilti Saw may be due to several factors. First, the blade tension might be inadequate; try changing the saw blade. Second, the saw blade could be blunt; change the saw blade, paying attention to the specification. Third, the guide cut may not have been made or was not straight; check whether the given guide values were adhered to. Fourth, the play at the guide rollers may exceed the specified value; check the play at the rollers and adjust them correctly. If adjustment isn't enough, replace the rollers or the guide rail. Fifth, the rail fastenings might be loose; check and refasten the rails. Sixth, the rail may be distorting; install additional rail supports. Seventh, a drop in performance may be due to the blade wandering off course; see the faul...

Summary

Information about the documentation

About this documentation and symbols

Prerequisite for safe handling and explanation of symbols.

Product symbols and information

Covers product symbols, stickers, and general info.

Safety

General Safety Rules and Warnings

Covers general rules, power tool warnings, and wall saw specifics.

Operational Safety Measures

Safety during operation, at danger areas, and transport.

Assembling the saw system

Installing Anchors and Rails

Steps for installing anchors and rail supports.

Mounting Rails for Cutting

Procedures for mounting rails for normal, bevel, and stair cutting.

Preparing the saw system for use

Mounting Saw Head and Connecting Supplies

Attaching saw head and connecting power/water.

Installing Inner Flanges and Saw Blades

Mounting flanges and saw blades for different cuts.

Working with the saw

Checks before sawing and guidelines

Pre-operation checks and cutting advice.

Dry-cutting application

Specific procedures for dry cutting operations.

Care and maintenance

Inspection and Maintenance Procedures

Routine checks and maintenance tasks.

Troubleshooting

Trouble and Fault Resolution

Diagnosing and fixing common problems.
