Hilti PD-I User Manual

2.9 Control panel
“Measure” button Quick start (when the tool is switched off, press the button briefly to
switch it on).
Begins distance measurement.
Activates the laser beam.
Activates continuous measuring mode (long press, approx. 2 sec.).
Stops continuous measuring mode.
Confirms the selected function or setting.
Left arrow button / right arrow button Used to navigate between functions and to make settings.
The “Clear” button has various func-
tions depending on the operating
status:
Stops continuous measuring (tracking).
Deletes the last measurement.
Goes one step back (short press).
Deletes all displayed measurements (long press).
Ends the function if no measurements have been taken.
“Menu” button
Opens the main menu.
On/off button Switches the tool on or off.
2.10 The items supplied
1 PD‑I laser range meter
2Batteries
1 Soft pouch
1 Operating instructions
1 Manufacturer’s certificate
1 Hand strap
1 Brochure for users
3 Accessories
Designation
Short designation
Target plate
1
PDA 50
Target plate
2
PDA 51
Target plate
3
PDA 52
Measuring extension PDA 72
Laser visibility glasses
4
PUA 60
1
With reflective coating (120x130 mm)
2
White (120x130 mm)
3
With reflective coating (210x297 mm)
4
For improved laser beam visibility under difficult lighting conditions.
en
21

Hilti PD-I Specifications

General

Type	Line/Point level
Product color	Red
Bluetooth	Yes
Display type	Digital
Maximum range	100 m
Country of origin	Germany
Leveling accuracy (±)	- mm/m
Distance measuring units	m
Self-leveling range (±)	- °
Battery type	AAA
Battery voltage	1.5 V
Number of batteries supported	2
Accuracy	1.5 mm
Minimum measurement distance	0.05 m
Quantity per shipping (inner) case	1 pc(s)
Number of shipping (inner) cases per master (outer) case	5 pc(s)
Battery included	No

Weight and Dimensions

Package depth	30 mm
Package width	80 mm
Package height	20 mm
Package weight	500 g
