4 Technical data
4.1 Technical data
SF 2-A12 SF 2H-A12
Rated voltage
10.8 V 10.8 V
Weight in accordance with EPTA procedure 01
1.1 kg 1.2 kg
Speed 1st gear
0 /min … 400 /min 0 /min … 400 /min
2nd gear
0 /min … 1,560 /min 0 /min … 1,560 /min
Torque (soft joint)
≤ 21 Nm ≤ 21 Nm
Torque range (15 settings)
0.5 Nm … 5 Nm 0.5 Nm … 5 Nm
Keyless chuck clamping range
0.8 mm … 10 mm 0.8 mm … 10 mm
Ø drill bit (softwood)
0.8 mm … 14 mm 0.8 mm … 14 mm
Ø drill bit (hardwood)
0.8 mm … 10 mm 0.8 mm … 10 mm
Ø drill bit (metal)
0.8 mm … 6 mm 0.8 mm … 6 mm
Ambient temperature for operation
−17 ℃ … 60 ℃ −17 ℃ … 60 ℃
Storage temperature
−20 ℃ … 70 ℃ −20 ℃ … 70 ℃
4.2 Battery
Battery operating voltage
10.8 V
Ambient temperature for operation
−17 ℃ … 60 ℃
Storage temperature
−20 ℃ … 40 ℃
Battery charging starting temperature
−10 ℃ … 45 ℃
4.3 Noise information and vibration values in accordance with EN 62841
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure.
The data given represent the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools, or is poorly maintained, the data can vary. This can
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the tool is switched off, or
when it is running but not actually being used for a job. This can significantly reduce exposure over the total
working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise emission values
SF 2-A12 SF 2H-A12
Emission sound pressure level (L
pA
)
72 dB(A) 76 dB(A)
Uncertainty for the sound pressure level (K
pA
)
3 dB(A) 3 dB(A)
Sound power level (L
WA
)
83 dB(A) 87 dB(A)
Uncertainty for the sound power level (K
WA
)
3 dB(A) 3 dB(A)
Total vibration
SF 2-A12 SF 2H-A12
Vibration emission value for drilling in metal (a
h, D
)
1.7 m/s² 1.7 m/s²
Uncertainty for drilling in metal (K)
1.5 m/s² 1.5 m/s²
Vibration emission value for hammer drilling in
concrete (a
h, ID
)
•/• 12.9 m/s²
Uncertainty impact drilling into concrete (K)
•/• 1.5 m/s²
