Hilti SF 22­A Manual

6 English
@
Side handle
;
Keyless chuck
=
Function setting ring
(screwdriving/drilling/hammer drilling)
%
Gear selector switch
&
Forward/reverse selector switch with safety
lock
(
Control switch (with electronic speed
control)
)
Grip
+
Release buttons with additional function
(charge status display activation)
§
Rating plate
/
Belt hook (optional)
:
Charge state and fault display (Li-ion
battery)
3.2 Intended use
The product described is a hand-held cordless drill / driver. It is designed to be used for driving and removing
screws and for drilling in steel, wood and plastic. The “'SFH” model is also suitable for hammer drilling in
masonry.
▶ Use only Hilti Li-ion batteries of the B22 series with this product.
▶ Use only the Hilti battery chargers of the C4/36 series for these batteries.
3.3 Liion battery display
The charge status of the Li-ion battery and malfunctions of the power tool are indicated by the display on
the Liion battery. The charge status of the Liion battery is displayed after pressing one of the two battery
release buttons.
Status Meaning
4 LEDs light. • Charge status: 75 % to 100 %
3 LEDs light. • Charge status: 50 % to 75 %
2 LEDs light. • Charge status: 25 % to 50 %
1 LED lights. • Charge status: 10 % to 25 %
1 LED blinks, the power tool is ready for use. • Charge status: < 10 %
1 LED blinks, the power tool is not ready for use. • The battery has overheated or is completely
discharged.
4 LEDs blink, the power tool is not ready for use. • The power tool is overloaded or has overheated.
Battery charge status cannot be displayed while the control switch is pressed and for up to 5 seconds
after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given in the Troubleshooting section.
3.4 Items supplied
Drill / driver, side handle, operating instructions.
• Other system products approved for use with this product can be found at your local Hilti Store or online
at: www.hilti.group | USA: www.hilti.com
4 Drill/driver
SF 22-A SFH 22-A
Rated voltage
21.6 V 21.6 V
Weight in accordance with EPTA procedure 01
2.52 kg 2.58 kg
Speed 1st gear
0 /min … 370 /min 0 /min … 370 /min
2nd gear
0 /min … 1,250 /min 0 /min … 1,250 /min
3rd gear
0 /min … 2,140 /min 0 /min … 2,140 /min
Torque (soft joint)
≤ 50 Nm ≤ 50 Nm
Torque range (15 settings)
2 Nm … 12 Nm 2 Nm … 12 Nm
Ø drill bit (softwood)
1.5 mm … 32 mm 1.5 mm … 32 mm
Printed: 24.09.2018 | Doc-Nr: PUB / 5152424 / 000 / 05
