Hilti SF 6-A22 Operating Instructions

8 English 2231427
*2231427*
5.4 Installing the side handle 2
CAUTION
Risk of injury! Loss of control over the rotary hammer drill.
▶ Check that the side handle is fitted correctly and tightened securely. Make sure that the clamps are
correctly seated in the grooves provided for the purpose.
1. Move the forward/reverse switch into the middle position.
2. Turn the grip to release the clamps of the side handle.
3. Seat the side handle clamping band fully on the housing and push the clamps into the grooves provided
for the purpose.
4. Turn the grip to tension the clamps of the side handle.
5.5 Fitting the belt hook (optional) 3
WARNING
Risk of injury. A falling power tool may present a risk of injury to yourself and others.
▶ Check that the belt hook is fitted securely before beginning work.
The belt hook allows the power tool to be attached to a belt worn by the operator. The belt hook can
be fitted to allow attachment on the left or right side of the body.
1. Remove the battery. → page 7
2. Insert the belt hook into the opening provided at the base of the product.
3. Secure the belt hook with the two screws.
4. Insert the battery. → page 7
5.6 Installing Hilti bit holder (optional) 4
1. Remove the battery. → page 7
2. Insert the bit holder into either the left or right opening provided at the base of the product.
3. Secure the bit holder with the two screws.
4. Insert the battery. → page 7
5.7 Installing the Hilti retaining strap (optional) 5
ATTENTION
Damage to the product and / or the retaining leash. Incorrect handling can result in damage to the
product and/or retaining leash.
▶ Do not use a metal chain as a retaining leash. Do not use a retaining leash with a length of more than
2,0 m (6 ft).
To avoid damage and injury, when working at a height it is advisable to use the Hilti retaining strap.
The retaining strap allows a securing cord or lanyard to be attached.
When working with the product, you must comply with national regulations for working at heights.
1. Remove the battery. → page 7
2. Insert the two tabs on the retaining strap into the slots on each side of the base.
3. Secure the retaining strap with the screws supplied.
4. Insert the battery. → page 7
5.8 Selecting the gear 6
▶ Select the gear.

Hilti SF 6-A22 Specifications

General

Tool type	Cordless Drill Driver
Battery voltage	21.6 V
Chuck capacity	1.5 - 13 mm
Number of gears	2
Battery Type	Li-ion
Chuck type	Keyless chuck
