*2231427*
2231427 English 9
5.9 Setting forward or reverse rotation 7
An interlock prevents switching while the motor is running.
The control switch is locked when the forward/reverse switch is in the middle position (safety lock).
▶ Set the forward/reverse selector switch to forward or reverse rotation, as applicable.
5.10 Inserting / removing the accessory tool 8
1. Set the forward/reverse switch to the middle position or remove the battery from the power tool.
2. Open the keyless chuck.
3. Insert the accessory tool into the chuck or remove it from the chuck.
4. Tighten the keyless chuck.
5. Check that the accessory tool is held securely.
5.11 Drilling 9
CAUTION
Risk of injury. The accessory tool may suddenly stall, causing the power tool to rotate about its own axis.
▶
Use the power tool with the side handle fitted and always hold it securely with both hands.
▶ Always grip the side handle at its outermost end.
CAUTION
Risk of injury. Risk of flying fragments.
▶ Wear eye protection.
▶
Set the torque and operating mode selector ring to the “Drilling” symbol .
5.12 Hammer-action drilling 9
SF 6H-A22
▶
Set the selector ring to the “Hammer-action drilling” position .
5.13 Screwdriving 9
▶ Set the torque and operating mode selector ring to the required torque.
5.14 Switching on
▶ Press the control switch.
▶ Speed is steplessly adjustable from minimum to maximum.
5.15 Switching off
▶ Release the control switch.
6 Care and maintenance
WARNING
Risk of injury with battery inserted !
▶ Always remove the battery before carrying out care and maintenance tasks!
Care of the product
• Carefully remove stubborn dirt.
• Carefully clean the air vents, if present, with a dry, soft brush.
• Use only a slightly damp cloth to clean the housing. Do not use cleaning agents containing silicone as
these can attack the plastic parts.
• Use a dry, clean cloth to clean the contacts of the product.
