Hilti SF 6-A22 Operating Instructions

6 English 2231427
*2231427*
3.2 Intended use
The product described is a hand-held cordless drill/driver. It is designed for drilling in steel, wood, plastic,
cellular concrete and masonry and for driving and removing screws.
▶ Use only Hilti Liion batteries of the B 22 series with this product.
▶ Use only the Hilti battery chargers of the C4/36 series to charge these batteries.
3.3 Items supplied
Drill / driver, side handle, operating instructions.
Other system products approved for use with this product can be found at your local Hilti Store or online at:
www.hilti.group | USA: www.hilti.com
3.4 Lithiumion battery status display
The Li-ion battery state of charge and malfunctions of the power tool are indicated by the display on the Liion
battery. The Liion battery state of charge is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. State of charge: 75 % to 100 %
3 LEDs light. State of charge: 50 % to 75 %
2 LEDs light. State of charge: 25 % to 50 %
1 LED lights. State of charge: 10 % to 25 %
1 LED blinks. State of charge: < 10 %
1 LED flashes, the power tool is not in working or-
der.
The battery has overheated or is completely dis-
charged.
4 LEDs flash, the power tool is not in working or-
der.
The power tool is overloaded or has overheated.
Battery state of charge cannot be displayed while the control switch is pressed and for up to 5 seconds
after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given in the Troubleshooting section.
3.5 ATC
The product is equipped with the ATC (Active Torque Control) quick-acting electronic cut-out.
If the accessory tool sticks or stalls, the product will suddenly pivot about its own axis in the opposite direction.
ATC detects this sudden pivoting movement of the product and switches the product off immediately.
For ATC to function correctly, the product must be free to pivot.
After an ATC cut-out, switch the product off and then on again.
3.6 Overload and overheating indicator
The power tool has an electronic system to protect against overload and overheating. The power tool
switches off automatically in the event of overload or overheating. The power tool might not restart
immediately when the control switch is pressed after being released (cooling phase).
4 Technical data
SF 6-A22 SF 6H-A22
Rated voltage
21.6 V
DC
21.6 V
DC
Weight
6.2 lb
(2.8 kg)
6.2 lb
(2.8 kg)
Speed 1st gear
0 /min … 490 /min 0 /min … 490 /min
2nd gear
0 /min … 2,000 /min 0 /min … 2,000 /min
Torque (soft joint)
≤ 65 Nm ≤ 65 Nm

Hilti SF 6-A22 Specifications

General

Tool type	Cordless Drill Driver
Battery voltage	21.6 V
Chuck capacity	1.5 - 13 mm
Number of gears	2
Battery Type	Li-ion
Chuck type	Keyless chuck
