English 15
6.1 Selecting the gear
▶ Select the desired gear by adjusting the two gear selector switches.
6.2 Setting forward or reverse rotation
An interlock prevents switching while the motor is running.
The control switch is locked when the forward/reverse switch is in the
middle position (safety lock).
▶ Set the forward/reverse switch to the desired direction of rotation.
6.3 Switching on
▶ Press the control switch.
Speed can be controlled steplessly right up to maximum by varying
how far the control switch is pressed in.
6.4 Screwdriving
1. Set the torque and operating mode selector ring to the required torque.
2. Set the forward/reverse switch to the desired direction of rotation.
Printed: 02.05.2019 | Doc-Nr: PUB / 5152170 / 000 / 03
