10 English 2153700
*2153700*
SID 22A SIW 22A
Impact speed
≤ 3,450 bpm ≤ 3,500 bpm
Torque adjustment
3 settings 3 settings
Large standard bolts
M8 to M16 M8 to M16
Large high-strength bolts
M6 to M12 M6 to M12
Socket/bit drive
1
/
4
″ hex. socket with
locking ring
1
/
2
″ square drive
with ball-notch re-
tention or
3
/
8
″ square
drive with locking
ring
Ambient temperature for
operation
1 ℉ … 140 ℉
(−17 ℃ … 60 ℃)
1 ℉ … 140 ℉
(−17 ℃ … 60 ℃)
Storage temperature
−4 ℉ … 158 ℉
(−20 ℃ … 70 ℃)
−4 ℉ … 158 ℉
(−20 ℃ … 70 ℃)
4.1 Setting the torque
The torque is selected by way of the torque selector button.
Model SID …
SID 14A
SID 22A
SID 14A SID 22A
Torque Setting I
37 ftlb
f
(50 Nm)
44 ftlb
f
(60 Nm)
Setting II
74 ftlb
f
(100 Nm)
81 ftlb
f
(110 Nm)
Setting III
111 ftlb
f
(150 Nm)
122 ftlb
f
(165 Nm)
Model SIW …
SIW 14A
SIW 22A
SIW 14A
1/2″ square drive
with ball-notch
retention
3/8″ square drive
with locking ring
Torque Setting I
59 ftlb
f
(80 Nm)
48 ftlb
f
(65 Nm)
Setting II
89 ftlb
f
(120 Nm)
85 ftlb
f
(115 Nm)
Setting III
136 ftlb
f
(185 Nm)
118 ftlb
f
(160 Nm)
