● Modification or manipulation of the tool other than
described in these operating instructions is not per-
missible.
● To avoid the risk of injury, use only original Hilti acces-
sories and additional equipment.
● Observe the information printed in the operating instruc-
tions concerning operation, care and maintenance.
● The tool and its ancillary equipment may present ha-
zards when used incorrectly by untrained personnel
or when used not as directed.
4.2 Important features of the tool
– Vibration-absorbing grip (rubber-padded)
– Smooth speed control
– Gearing and clutch with permanent lubrication
(grease)
– Automatic cut-out carbon brushes
– Forward / reverse rotation
– Function selector switch for rotary drilling/hammer
drilling
5. Technical data
Tool
Rated voltage 24 V
–––
- - -
Weight of tool including battery 3.8 kg (8.3 lb)
Dimensions (LxHxW) 325 x 260 x 92 mm (12.8 x 10.2 x 3.6 in)
Speed under no load 980 r.p.m.
Speed 900 r.p.m.
Hammering speed 0 … 74 Hz (0 … 4410 blows per min.)
Single impact energy 1.5 joules
Chuck TE-C
Hammer drilling dia. range in concrete and masonry 4 to 16 mm (
1
/
6
″ to
2
/
3
″)
Drilling using keyless chuck adaptor for
cylindrical drill bits
- Drilling dia. range in wood 3 to 13 mm (
1
/
8
″ to
1
/
2
″)
- Drilling dia. range in metal 3 to 10 mm (
1
/
8
″ to
2
/
5
″)
Screwdriving using bit adaptor
- Wood screws Up to 6 mm (
1
/
4
″)
- HUD screws Up to 6 mm (
1
/
4
″)
Speed control Electronic control switch
Forward / reverse Electrical switch with interlock to prevent activation
when running
Gearing section sealed to prevent entry of dust and with permanent lubrication (maintenance-free)
Battery B24/2.0 NiCd B24/2.4 NiCd B24/3.0 NiMH
Rated voltage 24 V
–––
- - -
24 V
–––
- - -
24 V
–––
- - -
Battery capacity 24 V × 2.0 Ah 24 V × 2.4 Ah 24 V × 3.0 Ah
= 48 Wh = 58 Wh = 72 Wh
Weight 1.38 kg (3 lb) 1.45 kg (3.2 lb) 1.43 kg (3.1 lb)
Temperature monitoring yes yes yes
Type of cell Nickel-cadmium Nickel-cadmium Nickel-metal hydride
SUB C type SUB C type SUB C type
No. of cells 20 20 20
Right of technical changes reserved!
