*2134960*
2134960 English 5
3 Description
3.1 Overview of the product 1
@
Chuck
;
Depth gauge
=
Function selector switch
%
Control switch
&
Supply cord
(
Side handle
)
Lockbutton for continuous operation
+
Service indicator
§
Reduced-power indicator
/
Power reduction button (50% power)
3.2 Version with detachable supply cord 2
@
Lockbutton
;
Connector on electric tool
=
Supply cord with keyed, releasable plug con-
nector
3.3 Intended use
The product described is an electrically powered combihammer with pneumatic hammering mechanism. It
is designed for drilling in concrete, masonry, wood and metal. The product can also be used for light- to
medium-duty chiseling on masonry and surface finishing work on concrete.
▶ The tool may be operated only when connected to a power source providing a voltage and frequency in
compliance with the information given on the type identification plate.
