Questions and Answers

L
lmathewsSep 16, 2025
Why is the service indicator lighting up on my Hilti Drill?
- A
  aprilcabreraSep 16, 2025
  If the service indicator is lighting up on your Hilti Drill, it could mean a couple of things related to the carbon brushes. It's possible that the carbon brush wear limit has almost been reached, in which case you should have them replaced at the next opportunity. Alternatively, if the carbon brushes have recently been changed, they may need to be run in. To do this, let the machine run under no load for at least 1 minute without interruption.
L
Leslie BellAug 25, 2025
What to do if the diamond core bit cannot be fitted into the chuck of my Hilti DD 150-U Drill?
- T
  Timothy MunozAug 25, 2025
  If you're having trouble fitting the diamond core bit into the chuck of your Hilti Drill, the issue might be that the core bit connection end or chuck is dirty or damaged. Try cleaning and greasing these parts. If that doesn't work, you may need to replace them.
J
Johnny ReyesAug 25, 2025
What to do if the Hilti DD 150-U multifunction display is not showing anything?
- E
  Elizabeth ClarkAug 26, 2025
  If the multifunction display is not showing anything, there could be several reasons. First, check that the PRCD is functioning and switched on. Second, verify that there isn't an interruption in the electric supply by testing another electric tool or appliance, and inspect the plug connections, supply cord, power supply line, and main supply fuse. Finally, if there's water in the motor, allow the drill to dry out completely in a warm, dry place.
D
Diana AdamsAug 26, 2025
Why does my Hilti Drill show a restart interlock?
- J
  Joseph MacdonaldAug 27, 2025
  A restart interlock can occur for several reasons. The motor may have overheated, in which case you should switch the drill off and then on again. A supply network fault or power interruption could also be the cause; check other power consumers and the extension cord length, then switch the drill off and on again. Water in the motor or exceeding the maximum running time with hole-starting mode activated can also trigger this, so dry the drill or switch it off and on again, respectively. Overloading the drill can also cause this issue; avoid repeated disengagement of the slip clutch.
L
lauraorozcoSep 17, 2025
Why is the drilling progress slow on my Hilti DD 150-U Drill?
- M
  Michelle PorterSep 17, 2025
  A slow drilling progress on your Hilti Drill could be due to several water-related or mechanical issues. The water flow rate might be too high or too low; adjust the water flow regulator accordingly. Also, ensure the carriage lock is released. Finally, dust may be hindering progress, so use a suitable dust removal system.
L
Lori KempNov 27, 2025
Why is the drilling progress rate decreasing on my Hilti DD 150-U Drill?
- L
  Lisa MartinNov 27, 2025
  A decrease in drilling progress can be attributed to several factors. You may have reached the maximum drilling depth, in which case you should remove the core and use a core bit extension. The core could be stuck in the core bit, so remove it. The core bit specification might be wrong for the base material, so select a more suitable one. High steel content, a defective core bit, wrong gear selection, low contact pressure, insufficient machine power, a polished core bit, incorrect water flow rate, an engaged carriage lock, or dust hindering progress could also be the cause. Address each of these potential issues accordingly: select the right gear, increase contact pressure, select the next lower gear, sharpen the core bit, adjust the water flow rate, release the carriage lock, or use a sui...
D
Donna ZamoraSep 8, 2025
Why can't the diamond core bit be fitted into the chuck of my Hilti DD 150-U Drill?
- O
  omooneySep 8, 2025
  If the diamond core bit cannot be fitted into the chuck, the core bit connection end or chuck might be dirty or damaged. Clean and grease the connection end and/or the chuck, or replace these parts.
H
Heather VelasquezSep 9, 2025
How to turn on Bluetooth on Hilti DD 150-U Drill?
- T
  Trevor CortezSep 10, 2025
  If Bluetooth is off, it means the Bluetooth is deactivated. To activate the Bluetooth function, simultaneously press the buttons indicated in the manual.
R
Rachel PrinceSep 3, 2025
Why does my Hilti Drill drilling system have too much play?
- M
  Michelle WoodSep 3, 2025
  Excessive play in the drilling system can stem from several issues. The core bit might not be securely tightened in the chuck; tighten it, remove it, rotate it approximately 90 degrees, and refit it. The core bit connection end or chuck could be defective, so check and replace them if necessary. Finally, the carriage might have too much play, requiring you to adjust the play between the rail and carriage.
A
anthony93Sep 1, 2025
What does 'remaining running time until the carbon brushes are changed' mean on my Hilti DD 150-U?
- D
  david27Sep 1, 2025
  This message indicates that the carbon brush wear limit has almost been reached. The drill will continue to run for a few hours until it shuts down automatically. You should have the carbon brushes replaced at the next opportunity.

Summary

Original Operating Instructions

Safety

General power tool safety warnings

Covers work area, electrical, and personal safety precautions.

Drill safety warnings

Specific safety instructions for all operations and using long drill bits.

Diamond drill safety warnings

Highlights safety aspects specific to diamond drilling operations.

Additional safety precautions

Further personal safety advice and power tool use/care guidelines.

Product Description

Parts of the tool and operating controls

Identifies components of the core drilling machine, drill stand, and accessories.

Intended use

Defines the product's designed purpose and operating conditions.

Multifunction Display Symbols

Technical Data

Diamond Core Drilling Machine Specifications

Lists technical specifications for the drilling machine.

Core Bit Diameter Ranges

Operation

Fitting Diamond Core Bit (BI+ Chuck)

Procedure for installing a diamond core bit in a BI+ chuck.

Fitting Diamond Core Bit (Alternative Chuck)

Steps for fitting a core bit using an alternative chuck type.

Removing Diamond Core Bit (BI+ Chuck)

How to safely remove a core bit from a BI+ chuck.

Removing Diamond Core Bit (Alternative Chuck)

Procedure for removing a core bit with an alternative chuck.

Selecting Operating Speed

Operating the PRCD

How to test and operate the PRCD for safety.

Using Hole-Starting Aid

Dry Drilling with Vacuum (Built-in Outlet)

Dry Drilling with Vacuum (No Outlet)

Wet Drilling (Hand-guided, No Collection)

Wet Drilling (Hand-guided, With Collection)

Wet Drilling with Drill Stand

Care and Maintenance

Diamond Core Drilling Machine Care

Guidance on cleaning and maintaining the drilling machine.

Replacing Carbon Brushes

Procedure for replacing worn carbon brushes in the machine.

Troubleshooting

Machine Not Working

Troubleshooting steps for machine malfunctions and non-operation.

Machine Running Issues

Troubleshooting steps for issues encountered when the machine is running.

Summary

Original Operating Instructions

Safety

General power tool safety warnings

Covers work area, electrical, and personal safety precautions.

Drill safety warnings

Specific safety instructions for all operations and using long drill bits.

Diamond drill safety warnings

Highlights safety aspects specific to diamond drilling operations.

Additional safety precautions

Further personal safety advice and power tool use/care guidelines.

Product Description

Parts of the tool and operating controls

Identifies components of the core drilling machine, drill stand, and accessories.

Intended use

Defines the product's designed purpose and operating conditions.

Multifunction Display Symbols

Technical Data

Diamond Core Drilling Machine Specifications

Lists technical specifications for the drilling machine.

Core Bit Diameter Ranges

Operation

Fitting Diamond Core Bit (BI+ Chuck)

Procedure for installing a diamond core bit in a BI+ chuck.

Fitting Diamond Core Bit (Alternative Chuck)

Steps for fitting a core bit using an alternative chuck type.

Removing Diamond Core Bit (BI+ Chuck)

How to safely remove a core bit from a BI+ chuck.

Removing Diamond Core Bit (Alternative Chuck)

Procedure for removing a core bit with an alternative chuck.

Selecting Operating Speed

Operating the PRCD

How to test and operate the PRCD for safety.

Using Hole-Starting Aid

Dry Drilling with Vacuum (Built-in Outlet)

Dry Drilling with Vacuum (No Outlet)

Wet Drilling (Hand-guided, No Collection)

Wet Drilling (Hand-guided, With Collection)

Wet Drilling with Drill Stand

Care and Maintenance

Diamond Core Drilling Machine Care

Guidance on cleaning and maintaining the drilling machine.

Replacing Carbon Brushes

Procedure for replacing worn carbon brushes in the machine.

Troubleshooting

Machine Not Working

Troubleshooting steps for machine malfunctions and non-operation.

Machine Running Issues

Troubleshooting steps for issues encountered when the machine is running.

Hilti DD 150-U Specifications

General

Power Source	Electric
Rated Input Power	2200 W
Drilling Range - Wet	25 - 162 mm
Drilling Range - Dry	25 - 162 mm
Gear number	3
Base material	Concrete
