2134960 English 7
TE 60AVR TE 60-ATC/AVR
Rated power input
1,350 W 1,350 W
Rated current input
7.2 A 7.2 A
Weight in accordance with EPTA proce-
dure 01/2003
6.8 kg 7.8 kg
Single impact energy in accordance with
EPTA procedure 05
7.8 J 7.8 J
Hammer drill bits, Ø
12 mm … 55 mm 12 mm … 55 mm
Ø Breach bits
40 mm … 80 mm 40 mm … 80 mm
Ø Percussion core bits
45 mm … 100 mm 45 mm … 100 mm
Ø PCM diamond core bits
•/• 42 mm … 102 mm
Ø drill bits for metal
10 mm … 20 mm 10 mm … 20 mm
Ø Drill bits for wood
10 mm … 32 mm 10 mm … 32 mm
Chuck
TEY TEY
4.2 Noise information and vibration values in accordance with EN 62841
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure.
The data given represent the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools, or is poorly maintained, the data can vary. This can
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the power tool is switched
off, or when it is running but not actually being used for a job. This can significantly reduce exposure over
the total working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise information
TE 60AVR TE 60-ATC/AVR
Sound power level (L
WA
)
107 dB(A) 111 dB(A)
Uncertainty for the sound power level (K
WA
)
3 dB(A) 3 dB(A)
Sound pressure level (L
pA
)
96 dB(A) 100 dB(A)
Uncertainty for the sound pressure level (K
pA
)
3 dB(A) 3 dB(A)
Total vibration
TE 60AVR TE 60-ATC/AVR
Hammer drilling in concrete (a
h, HD
)
10.5 m/s² 7.2 m/s²
Chiseling (a
h,Cheq
)
9.1 m/s² 6.2 m/s²
Uncertainty (total vibration)
1.5 m/s² 1.5 m/s²
5 Operation
5.1 Preparations at the workplace
CAUTION
Risk of injury! Inadvertent starting of the product.
▶ Unplug the supply cord before making adjustments to the power tool or before changing accessories.
Observe the safety instructions and warnings in this documentation and on the product.
5.1.1 Fitting the side handle 3
1. Release the side handle clamping band by turning the handle grip.
2. Slide the side handle clamping band over the tool holder from the front and into the recess provided.
