4. Technical data
Rated power input TE46 1050 W
TE56 / TE56-ATC 1100 W
Rated voltage 100 V 110 V 120 V 220 V 230 V 240 V
Rated current input TE46 15.8 A 13.6 A 13.6 A 6.8 A 6.5 A 6.3 A
TE56 / TE56-ATC 16.3 A 14.2 A 14.2 A 7.0 A 6.8 A 6.6 A
Mains frequency 50–60 Hz
Weight of tool TE46 / TE56 5.9 kg
TE56-ATC 6.6 kg
Dimensions (l × w × h) TE46 468×95×240 mm
TE56 475×95×240 mm
TE56-ATC 475×95×260 mm
Hammer drilling speed 480 r.p.m.
Drilling speed without hammering
action TE56 / TE56-ATC 720 r.p.m.
Single impact energy
(full hammering power) 7.0 Nm (J)
Single impact energy
(reduced hammering power) 3.5 Nm (J)
Drill bit diameter range in concrete / TE46 6–32 mm dia
masonry (hammer drilling) TE56 / TE56-ATC 12–40 mm dia.
Breach bits TE46 40 mm dia.
TE56 / TE56-ATC 40–66 mm dia.
Percussion core bits TE46 50–90 mm dia.
TE56 / TE56-ATC 45–90 mm dia.
Diamond core bits PCM TE56-ATC 42–87 mm dia.
Diameter range with drill bits for wood 10–32 mm dia.
Diameter range with drill bits for metal Up to 20 mm dia.
Drilling performance in medium-hard concrete 20 dia.: 350 mm/min.
Double insulated (in accordance with EN 50144) Protection class II Z
Mechanical slip clutch
ATC active torque control (TE56-ATC)
Vibration-absorbing grip and side handle
Interference immunity In accordance with EN 55014-2
Radio and television interference suppression In accordance with EN 55014-1
User information as per EN 61000-3-11
Switching operations cause short voltage drops. If the mains electric supply conditions are unfavourable,
other tools / machines can be impaired. If the main electric supply impedance is less than 0.15 Ohms, no
disruptions / disturbances need be expected.
Noise and vibration information (measured in accordance with EN 50144):
Typical A-weighted sound
power level (LwA): 105 dB (A)
Typical A-weighted sound
pressure level (LpA): 92 dB (A)
Wear ear protection!
Typical weighted vibration TE46 / TE56 7 m/s
2
at the grips: TE56-ATC 6.5 m/s
2
Right of technical changes reserved
