HI 800 101 HIMatrix Engineering Manual
5.1.1 Field bus interfaces of the controller
Steuerung FB1 FB2 FB3
F20
free built-in RS485
1)
---
F30
free
free
built-in RS485
1)
F35
free
free
built-in RS485
1)
F60
free
free
---
Table 6: field bus equipment
1)
RS485 field bus interfaces can be used for Modbus (Master or Slave) or CUT.
After buying a license you can get a new activation code via the homepage
http://himatrix.hima.com. For further information please contact the HIMA support:
Phone: +49 6202 709 185 or –424 or via E-mail: support@hima.com
Composition of the part number
98.22xy.....
x: Option for first slot
y: Option for second slot
Options for x and y:
0: Interface is not used
1: RS485 (Modbus master or slave, specified by the license code)
2: Profibus master
3: Profibus slave
4: Interbus master
5: RS 232
Examples:
F60: 98.2212126 ... Slot 1: RS485, Slot 2:Profibus Master
F30: 98.2232415 ... Slot 1: Profibus Slave, Slot 2:Profibus Master
F20: 98.2210417 ... Slot 1: RS485
F35: 98.2242416 ... Slot 1: Interbus Master, Slot 2:Profibus Master
25 of 61
