HIMA HIMax X-DI 32 02 User Manual

X-DI 32 02 4 Start-up
HI 801 017 E Rev. 4.00 Page 37 of 56
4.3.2 Tab: I/O Submodule DI32_02
The I/O Submodule DI32_02 tab contains the following statuses and parameters:
Name R/W Description
Enter these statuses and parameters directly in the Hardware Editor.
Name R Module name
Show Signal Overflow W
Show signal overflow with Field LED
(activated/deactivated).
Default setting: Activated
Show Supply Overcurrent W
Show supply overcurrent with Field LED
(activated/deactivated)
Default setting: Activated
Supply 1 on W
Use module's proximity switch supplies for Channel 1 to
Channel 8 (activated/deactivated).
Default setting: Activated
Supply 2 on W
Use module's proximity switch supplies for Channel 9 to
Channel 16 (activated/deactivated).
Default setting: Activated
Supply 3 on W
Use module's proximity switch supplies for Channel 17 to
Channel 24 (activated/deactivated).
Default setting: Activated
Supply 4 on W
Use module's proximity switch supplies for Channel 25 to
Channel 32 (activated/deactivated).
Default setting: Activated
Name Data type R/W Description
The following statuses and parameters can be assigned global variables and used in the user program.
Diagnostic Request DINT W
To request a diagnostic value, the appropriate ID must be
sent to the module using the parameter Diagnostic
Request (see Chapter
4.3.5 for coding details).
Diagnostic Response DINT R
As soon as Diagnostic Response returns the ID of
Diagnostic Request (see
4.3.5 for coding details),
Diagnostic Status contains the diagnostic value requested.
Diagnostic Status DWORD R
Requested diagnostic value in accordance with Diagnostic
Response.
The IDs of Diagnostic Request and Diagnostic Response
can be evaluated in the user program. Diagnostic Status
only contains the requested diagnostic value when both
Diagnostic Request and Diagnostic Response have the
same ID.
Background Test Error BOOL R TRUE: Background test is faulty
FALSE: Background test is free of faults
Restart on Error BOOL W
Using the parameter Restart on Error, each I/O module
that has switched off permanently due to faults can be
forced to re-adopt the RUN state. To do this, set the
Restart on Error parameter FALSE to TRUE.
The I/O module performs a complete self-test and only
enters the RUN state if no faults are detected.
Default setting: FALSE
