3 Product Description X-DI 32 02
Page 24 of 56 HI 801 017 E Rev. 4.00
3.6.5 Connector Boards with Cable Plug
Mono Redundant Threefold redundant
X-CB 005 03 X-CB 005 04 X-CB 005 07
cba
cba
1
2
cba
1
2
3
4
4
3
X-CB
005 03
X-CB
005 04
X-CB
005 07
I/O Module Plug
Connection to the Field Zone (Cable Plug in
Row 1)
Connection to the Field Zone (Cable Plug in
Row 32)
Coding for Cable Plugs
Figure 7: Connector Boards with Cable Plug
