Hinkley HOVER FLUSH 72 - FINISHING THE INSTALLATION

08 hinkley.com
|
FINISHING THE INSTALLATION
1
2
Move fan into position over the mounting bracket and secure
with the 4 screws provided. (Fig. 1)
Raise up decorative ring and line up the 4 slots on the fan
motor with the 4 tabs on the decorative ring. Once lined up,
slide the decorative ring and secure it to the top of the fan
motor until snug. (Fig. 2)
Mounting
bracket
Fig. 1
Decorative
ring
Studs
Fan
motor
Fig. 2
Screws
