Performing Insulation Resistance Testing
10
Verify that the measured value is greater than the insulation
resistance value specied by the vehicle manufacturer.
Example: Inverter-side high-voltage bus cable negative electrode and
chassis ground (GND)
IR4059
Inverter side Traction battery side
33
4, 7, 94, 7, 9
55
66
Black
Red
