Appendix
Potential equalization test (bonding)
FROM TO Measured value Comment
Insulation resistance test
Measured value Comment
Battery side Between (+) HV+
and (-) GND
Battery side Between (+) HV-
and (-) GND
Inverter side Between (+) HV+
and (-) GND
Inverter side Between (+) HV-
and (-) GND
Inverter side Between (+) GND
and (-) HV+
Inverter side Between (+) GND
and (-) HV-
Memo
