2.5 LAN Settings and Connection
16
LAN Settings
7
Select the default gateway.
If the default gateway does not need to be set, for
example, when connecting the instrument and
computer on a one-to-one basis using a cross ca-
ble, leave this set to OFF.
Default gateway Settings
8
Use or to set the default gate-
way.
Press to confirm the setting.
LAN Settings
9
Select the port number.
HIOKI IM3570A983-08
