3.3 GP-IB Connection and Settings (when connected to the Z3000)
25
Chapter 3 Model IM3523 Connection and Setting
3
Select the terminator setting.
4
Set the GP-IB address.
Valid setting range: 0 to 30
5
Select.
1
LF with CR+EOI
2
LF with EOI
Select.
1
Select the GP-IB address setting.
2
You will return to the measure-
ment screen.
