5.4
GP-IB Connection and Settings (when connected to the Z3000)
61
Chapter 5 Model IM7580 Connection and Setting
Connect the GP-IB cable to the GP-IB connector.
5.4 GP-IB Connection and Settings
(when connected to the Z3000)
Connecting the GP-IB Cable
Setting GP-IB
Recommended cable:
9150-02 GP-IB connection cable (2 m)
You can configure the setting from any of mode, mode and mode.
Procedure
LCR Measurement Screen
1
Interface Settings
To Next Page
