HIPOTRONICS 880PL-HD - Technical Data

Introduction
5
1.3 Technical Data: 880PL-HD
1.3.1 General Specifications
Power Input
90 – 264VAC 50/60Hz
Operating Temperature
14 … 122°F (-10 … 50°C)
Storage Temperature
-4 … 158°F (-20 … 70°C)
Humidity
5 … 95% R.H. non-condensing
ECCN #
3A992.A
HTS US Code
9030.39.0100
1.3.2 Model Specifications
Model #
880PL-HD
Output Voltage (DC)
0 … -80kV (+ for /P)
Output Current
0 … -10mA (+ for /P)
Measurements
Resolution
Accuracy
Voltage
0.1kV
+/- 1.5% of Reading +/- 0.2%
F.S.
Current
0.1uA
+/- 1.5% of Reading +/- 0.2%
F.S.
Resistance
10kΩ
+/- 1.5% of Reading +/- 0.2%
F.S.
Dimensions
19.45” x 13.7” x 20”
49.3cm x 34.8cm x 50.7cm
Weight
78lbs
Duty Cycle
1hr ON, 1hr OFF
