56
Installation MACH 1000
Release
04
12/2015
Power supply
types C and L
Rated voltage range DC 24 V ... 48 V
Devices with certification type “T”: 36 V
Voltage range DC incl. maximum
tolerances
18 V ... 60 V
Connection type C 3-pin spring-loaded terminal for copper
wire with cross-section AWG 20-12 (0.5
mm² ... 3.0 mm²) and stripping length 12
mm
Connection type L 3-pin terminal block
Power loss buffer > 10 ms at 20.4 V DC
Peak inrush current 15 A
Input voltage for
device variants
with PoE
Rated voltage range DC 110 V ... 250 V
Voltage range DC incl. maximum
tolerances
77 V ... 300 V
Rated voltage range AC 110 V ... 230 V
Voltage range AC incl. maximum
tolerances
90 V ... 265 V, 47 Hz ... 63 Hz
Output voltage
for device
variants with PoE
48 V DC ± 5%
Back-up fuse Power unit types C and G Nominal rating:
Characteristic:
6.3 A
slow blow
Power unit types L and M Nominal rating:
Characteristic:
2.5 A
slow blow
Signal contact Nominal value for AC I
max
=2A at U
max
=230V
Nominal value for DC I
max
=2A at U
max
=30V
I
max
=0.2 A at U
max
= 125 V
I
max
=0.1A at U
max
= 250 V
Connection type for power unit
types C and G
2-pin spring-loaded terminal for copper
wire with cross-section AWG 20-12
(0.5 mm² ... 3.0 mm²) and stripping length
12 mm
Connection type for power unit
types L and M
2-pin terminal block
Climatic conditions
during operation
Minimum clearance around
the device
Top and bottom sides of device: 1.97 in
(5 cm)
Left and right device side: 3.94 in (10 cm)
Ambient air temperature
a
Standard +32 °F ... +140 °F
(0 °C ... +60 °C)
Extended
bcdef
−40 °F ... +185 °F
(−40 °C ... +85 °C)
Humidity 5 % ... 95 % (non-condensing)
Air pressure Up to 2000 m (795 hPa), higher altitudes
on request
