Hirschmann MACH 1030 User Manual

Installation MACH 1000
Release 04 12/2015
55
7 Technical data
 General technical data
Dimensions
W × H × D
Devices with terminal connection
voltage supply
(power unit types C and G)
448 × 310 × 44 mm
(without brackets)
Devices with pluggable voltage
supply
(power unit types T and M)
448 × 345 × 44 mm
(without brackets)
Weight (incl.
redundant power
unit or PoE
power unit)
MAR1020-... fully equipped max. 4.6 kg
MAR1030-... fully equipped max. 4.7 kg
MAR1120-... fully equipped
(incl. redundant power unit)
max. 5.4 kg
MAR1130-... fully equipped
(incl. redundant power unit)
max. 5.5 kg
MAR1122-... fully equipped max. 5.5 kg
MAR1132-... fully equipped max. 5.6 kg
MAR1022-... fully equipped max. 4.7 kg
MAR1032-... fully equipped max. 4.8 kg
Weight MAR1020-... basic device approx. 3.9 kg
MAR1030-... basic device approx. 4.0 kg
MAR1120-... basic device approx. 4.7 kg
MAR1130-... basic device approx. 4.8 kg
MAR1122-... basic device approx. 5.1 kg
MAR1132-... basic device approx. 5.2 kg
MAR1022-... basic device approx. 4.3 kg
MAR1032-... basic device approx. 4.4 kg
Optional PoE power unit approx. 0.3 kg
Optional second power unit additional approx. 0.3 kg
Per 6 ports (3 modules) additional approx. 0.1 kg
Per M12 module additional approx. 0.09 kg
Power supply
types G and M
Rated voltage range AC 100 V ... 240 V, 50 Hz ...60 Hz
Voltage range AC incl. maximum
tolerances
90 V ... 265 V, 47 Hz ... 63 Hz
Rated voltage range DC 110 V ... 250 V
Devices with certification type “T”: 110 V
Voltage range DC incl. maximum
tolerances
77 V ... 300 V
Connection type G 3-pin spring-loaded terminal for copper
wire with cross-section AWG 20-12 (0.5
mm² ... 3.0 mm²) and stripping length 12
mm
Connection type M 3-pin terminal block
Power loss buffer > 20 ms at 230 V AC
Peak inrush current 14 A
