2.3.2 Vertical mounting on the wall
 Use the pre-mounted brackets included in the delivery.
 Additionally attach 2 brackets to the back of the device.
You can obtain additional brackets as accessories (see on page 64
“Accessories”).
 Fasten the device by screwing the brackets to the wall.
WARNING
FIRE HAZARD
Install the device in a fire protected shell if you are mounting it vertically.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
