62
Installation MACH 1000
Release
04
12/2015
MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Product
code
M-FAST-
SFP-...
Wave
length
Fiber System
attenuatio
n
Example
for F/O line
length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber
attenuation
BLP/
dispersion
-MM/LC... MM 1310 nm 50/125 µm 0-8 dB 0-5 km 1.0 dB/km 800 MHz×km
-MM/LC... MM 1310 nm 62.5/125 µm 0-11 dB 0-4 km 1.0 dB/km 500 MHz×km
-SM/LC... SM 1310 nm 9/125 µm 0-13 dB 0-25 km 0.4 dB/km 3.5 ps/(nm×km)
-SM+/LC... SM 1310 nm 9/125 µm 10-29 dB 25-65 km 0.4 dB/km 3.5 ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10-29 dB 47-104 km 0.25 dB/km 19 ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10-29 dB 55-140 km 0.18 dB/km
b
b. with ultra-low-loss optical fiber
18 ps/(nm×km)
Table 11: Fiber port 100BASE-FX (SFP fiber optic Fast Ethernet Transceiver)
Product
code
Wave
length
Fiber System
attenuati
on
Example
for F/O line
length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber
attenuatio
n
BLP/
dispersion
-FF MM 820 nm 50/125 µm 0-9.5 dB 0-2.1 km 3.0 dB/km 400 MHz*km
-FF MM 820 nm 62.5/125 µm 0-12.5 dB 0-3.0 km 3.2 dB/km 200 MHz*km
Table 12: F/O port 10BASE-FL
Product
code
Wave
length
Fiber System
attenuati
on
Example
for F/O line
length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber
attenuatio
n
BLP/
dispersion
-JJ, -MM, -
NN, -BB
MM 1300 nm 50/125 µm 0-8 dB 0-5 km 1.0 dB/km 800 MHz*km
-JJ, -MM, -
NN, -BB
MM 1300 nm 62.5/125 µm 0-11 dB 0-4 km 1.0 dB/km 500 MHz*km
-VV, -UU SM 1300 nm 9/125 µm 0-16 dB 0-30 km 0.4 dB/km 3.5 ps/(nm*km)
-LL LH 1550 nm 9/125 µm 3-29 dB 14-104 km 0.25 dB/km; 19 ps/(nm*km)
-GG LH 1550 nm 9/125 µm 14-47 dB 67-176 km 0.25 dB/km 19 ps/(nm*km)
Table 13: F/O port 100BASE-FX
TP port
Length of a twisted pair segment max. 100 m (cat5e cable with 1000BASE-T)
Table 14: TP port 10BASE-T / 100BASE-TX / 1000BASE-T
