Installation MACH102
Release
06
09/2014
29
Connecting the PoE supply voltage to the M1-8TP-RJ45 PoE
media module (optional)
The PoE power is supplied via the wire pairs transmitting the signal
(phantom voltage).
The individual ports (joint PoE voltage) are not electrically insulated from
each other.
The following values apply to the PoE supply voltage of the module:
WARNING
ELECTRIC SHOCK
Supply solely 48 V DC SELV voltage (PoE) or 54 V DC SELV voltage
(PoE+) to the M1-8TP-RJ45 PoE media module.
For the PoE power supply to the M1-8TP-RJ45 PoE media module, use a
fuse of 5 A—slow-blow characteristic.
Install this device solely in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
Never insert sharp objects (small screwdrivers, wires, etc.) into the connec-
tion terminals for the power lines, and do not touch the terminals!
Non-adherence to these instructions can lead to death, serious
physical injury or material damage.
WARNING
FIRE HAZARD
Disconnect the PoE voltage supply before removing the M1-8TP-RJ45 PoE
media module.
Non-adherence to these instructions can lead to death, serious
physical injury or material damage.
Rated voltage 48 V DC SELV
Minimum voltage 46 V DC
Maximum voltage 57 V DC
