Hirschmann MACH102 Series User Manual

40
Installation MACH102
Release 06 09/2014
 EMC and immunity
 Network range
Note: The line lengths specified for the transceivers apply for the respec-
tive fiber data (fiber attenuation and BLP/dispersion).
EMC interference
immunity
EN 61000-4-2 Electrostatic discharge
Contact discharge
Air discharge
6 kV
8 kV
EN 61000-4-3 Electromagnetic field
80 MHz ... 3000 MHz 20 V/m
EN 61000-4-4 Fast transients (burst)
- Power line
- Data line
2 kV
4 kV
EN 61000-4-5 Voltage surges
- Power line, line/line:
- Power line, line/earth
- Data line
1 kV
2 kV
4 kV
EN 61000-4-6 Line-conducted interference voltages
150 kHz - 80 MHz 10 V
EN 61000-4-9 Pulse magnetic fields 300 A/m
EMC interference
emission
EN 55022 Class A Yes
FCC 47 CFR Part 15 Class A Yes
TP port
Length of a twisted pair segment max. 100 m/328 ft (for cat5e cable)
Table 8: TP port 10BASE-T / 100BASE-TX / 1000BASE-T
Product
code
M-FAST-
SFP-...
Wave
length
Fiber System
attenua-
tion
Example
for F/O line
length
a
a. including 3 dB system reserve when compliance with the fiber data is observed
Fiber atten-
uation
BLP/
dispersion
-MM/LC... MM 1310 nm 50/125 µm 0-8 dB 0-5 km 1.0 dB/km 800 MHz×km
-MM/LC... MM 1310 nm 62.5/125 µm 0-11 dB 0-4 km 1.0 dB/km 500 MHz×km
-SM/LC... SM 1310 nm 9/125 µm 0-13 dB 0-25 km 0.4 dB/km 3.5
ps/(nm×km)
-
SM+/LC...
SM 1310 nm 9/125 µm 10-29 dB 25-65 km 0.4 dB/km 3.5
ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10-29 dB 47-104 km 0.25 dB/km 19 ps/(nm×km)
-LH/LC... SM 1550 nm 9/125 µm 10-29 dB 55-140 km 0.18 dB/km
b
18 ps/(nm×km)
Table 9: Fiber port 100BASE-FX (SFP fiber optic Fast Ethernet Transceiver)
